15
Best Practice: Please do not disconnect DC connection while the system is
working. Ensure that no current is flowing in the DC wires prior to disconnecting.
If necessary, use an opaque to cover the PV module prior to disconnecting the
PV module. Always disconnect AC power before disconnecting the PV module
from the Envertech microinverter. Disconnecting AC connectors of the
microinverters is also a means of cutting off AC power.
WARNING: The AC and DC connectors on the cabling are rated as a disconnecting
point only when used with an Envertech microinverter.
WARNING: Envertech microinverters are powered by DC power from the PV
modules. Please disconnect and reconnect DC power to check the LED blinks 1
minute after DC is applied.
1. Make sure AC breakers are on.
2. Check the connection to the utility grid and verify that the grid voltage is within
allowable ranges shown in the Technical Data section.
3. Verify that AC voltage at all solar power circuit breakers of the load centers
are within the ranges shown in the following table.
4. Verify that AC line voltage at the junction box for each AC branch circuit is
within the ranges required by local grid standards.
Single-Phase 230 VAC
Three-Phase 230 VAC
L to N
189 to 260VAC
L1 to L2 to L3
310 to 460VAC
5. Confirm if the microinverter side is connected to the grid by measuring the
voltage from AC line to line and line to neutral.
6. Visually check if AC branch circuit connection is correctly done. Reinstall if
necessary.-Check also for damage, such as rodent damage.
7. Make sure that all circuit breakers are off.
8. Disconnect and re-connect the PV modules’ DC connectors with
microinverters. The LED status of each microinverter will blink green to indicate
normal start-up operation soon after DC power is applied (less than one minute).
9. Attach an ammeter clamp to one conducting wire of the DC cables from the
PV module to measure the microinverter’s current. This will be under 1 Amp if
AC is disconnected.
10. Check the DC connection between the microinverter and the PV module. The
connection may need to be tightened or reseated. If the connection is worn out
or damaged, it needs replacement.
11. Verify with your utility company that grid frequency is within the regulated
range.
8.3 Disconnect Microinverters from PV Modules
If your problems are still unsolved with the steps above, please contact
Envertech tech support through www.envertec.com. If Envertech approves the
replacement, please take off the microinverter according to the following
instructions. In order to ensure the disconnection between the microinverter
and the PV Module will not be done while the microinverter is at working status,
please strictly follow the steps below.
1. Turn off AC branch circuit breaker.
2. Disconnect the microinverters in the following procedure:
Pull the AC connectors of both sides of the microinverters in the opposite
direction with appropriate force.
3. Cover the PV module with an opaque, and then disconnect the PV module DC
connectors from the microinverter.
4. Loosen the grounding screw and remove the grounding wire.
5. Take off the microinverter from the PV frame.
