Envertech EVT2000 User Manual

3
3. Product Information
Note: For optimum reliability and to comply with warranty conditions, the
EVT2000 microinverter must be installed according to the instructions in this
manual.
3.1 Overview
3.2 Major Characteristics
Envertech microinverters have the following characteristics which make
Envertech microinverters “Highly Efficient, Highly Reliable, Highly Cost Effective”:
Low DC input voltage.
Wide MPPT voltage range ensures high yield under various weather conditions.
High MPPT accuracy ensures minimum power loss during converting. Complete
set of protective functions.
Also, the following protective functions are integrated into Envertech
microinverters: Internal overvoltage/undervoltage protection
Faulty grounding protection Grid monitoring
Current monitoring in grounding DC current monitoring
EVT2000 can be adapted to almost all modules. Before installation, please check
the parameters of the microinverters and modules to ensure that they are
compatible.
3.3 Datasheet
Model
EVT2000
Input Data（DC）:
Recommended Input Power Range (STC)
(250W
～
650W)*4
Max. DC input (V)
60V
Isc PV (Absolute Max.) (A)
25 A
Operating Range (V)
16V-60V
Max. Input Current (A)
18A*4
Mppt Voltage Range (V)
22V-50V
Output Data（AC）
Nominal Voltage (Vac)
220V/230V
Voltage Range (Vac)
189V-260v
Current (Max. continuous) (A)
9.09A
Frequency (Hz)
50Hz/60Hz
Frequency Range (Hz)
47.5-52.5Hz/57.5-62.5Hz
Power (Max. continuous) (W)
2000W
Power Factor /Rated(default)
+/-0.90
Total Harmonic Distortion
<3%
Maximum Units Per Branch(12AWG
Cable)
2 Units
Efficiency
Peak Efficiency
96.5%
MPPT Efficiency
99.9%
Nighttime Power Consumption
<100mW
