OPERATING INSTRUCTIONS
Please read the SAFETY PRECAUTIONS section in this manual before you start the unit for the first time or
when the gas supply has been turned off or when ever the gas cylinder has been changed.
Make sure the orifices, venturis, and main burners are free from obstructions. Perform a gas leak check as
described on page 3 of this manual.
IGNITION:
1 The unit is equipped with a battery operated ignition system that will direct a spark to all burners at the
same time.
2 Ensure that all burner control knobs are in the “OFF” position.
3 Turn fuel supply “ON” at the source.
4 Open the lid to the barbecue and do not put your head over Gas Grill before lighting, push the center
gas control knob counter clockwise to the high flame setting and depress the igniter button until the
burner lights. To light other burners turn the desired knob counter clockwise and depress igniter button
until main burner lights. Use this same procedure to ignite rear burner and side burner (hot plate) if
equipped.
5 Ensure that the burner is lit and check the flame for proper appearance and operation. (See next page)
If the electric igniter does not operate, remove the grills from the unit and the flame diffusers beneath
the grills and light the burners using a match or flame taper.
NOTE: Each burner must have the ignition button depressed in order to ignite each burner.
This lighting operation should only take 4-6 seconds. IF THE BURNERS DO NOT IGNITE turn gas knobs to
the “OFF” position and wait 5 minutes to clear any gas that could have accumulated in and around the
barbecue.
TEMPERATURE SETTING:
The temperature settings on this barbecue are labeled high to low flame and the control knob can be set any
were in this temperature range on all burners. To preheat this unit, close the lid and monitor the thermometer
located on the lid.
TURNING THE UNIT “OFF”:
Turn the gas control knob clockwise to the “OFF” position when the unit is not being used or when you have
finished cooking with the barbecue. Always turn the main gas supply “OFF” at the source when not in use.
Depress ignitor when
burner knob has been
Turn burner knob to
the highest position
REAR BURNER LEFT BURNER RIGHT BURNER IGNITOR
14
