18
Storm
Collar
Roof
Flashing
Roof
Rafters
Roof
Sheathing
Ceiling
Joist
Vertical
Vent
Pipe
Outside
Vent
Termination
Exterior
Wall
Sheathing
Rain
cap
-
ensure
cap
is
at
least
2'
(610mm)
above
the
roof
at
the
lowest
point
Inst
alla
tion
T
HROUGH
W
ALL
V
ERTICAL
I
NSTALLATION
W
ITH
E
XHAUST
B
LOWER
:
Ref
er
to
I
NSTALLATION
-
I
NSTALLATION
WITH
E
XTERIOR
M
OUNTED
E
XHAUST
B
LOWER
and
I
NSTALLATION
-
O
UTSIDE
V
ERTICAL
I
NSTALLATIONS
.
Ensure
that
vent
pipe
is
properly
secured
to
wall
using
wall
straps.
Maintain
clearances
to
combustibles on vent pipe as well as unit.
Figure 21: Exhaust Blower Installation; V
ertical T
ermination.
17
19
