Enviro Maxx - Dimensions & Specifications

21
13
/16" (554mm)
15
15
/16"
(404mm)
21
9
/16"
(548mm)
41
1
/4"
(1047mm)
41
13
/16"
(1063mm)
23
13
/16" (605mm)
25
5
/8" (650mm)
26
3
/4" (680mm)
25
1
/16" (637mm)
Installation
DIMENSIONS & SPECIFICATIONS:
Figure 2: Dimensions of Maxx.
6
Table 1: Maxx Specifications.
Testing Standard Frequency Voltage
ASTM 1509-04 60 Hz 110 - 120 V
Fuel type Current Max Power
wood pellets - 6mm (”) dia. 3.6 Amps 432 Watts
Description Hopper Capacity Consumption on Low
Residential Wood Pellet Heater up to 130 lb (59 Kg) 1.7 lb/hr (0.77 Kg/hr)*
Weight (with full hopper) Consumption on High
455 lb (206 Kg) 7.6 - 8.3 lb/hr (3.45-3.76 Kg/hr)*
*Note: Consumption will vary with the type of fuel used.
