ATA 21-00-23
Page | 12
Revision 10
June 1, 2017
SUBTASK 21-00-23-99F-003
1.3 Standard Torque Values:
TYPE FASTENER
DESCRIPTION/LOCATION
TORQUE
.25-28 SET SCREW
ALL OTHER LOCATIONS
40-50 IN LBS
.25-28 SET SCREW
EVAPORATOR BLOWER WHEEL
12-15 IN LBS
6-32 SCREW
AN500-6-6, MS35265-30/-43, MS35206-
228, ALL LOCATIONS
8-10 IN-LBS
8-32 SCREW
AN500-A8-6, MS35265-45, ALL
LOCATIONS
12-15 IN-LBS
10-32 SCREW/BOLT
ALL LOCATIONS
20-25 IN-LBS
M10X1.2525MM
COMPRESSOR BOLT
175-200 IN LBS
¼-28-UNF
ALL LOCATIONS
50-70 IN-LBS
5/16-24UNF
ALL LOCATIONS
100-140 IN-LBS
3/8-24UNF
AN6-10A, AN6-14A, ALL LOCATIONS
160-190 IN-LBS
5/8-18 PLUMBING
CONNECTIONS
RECEIVER DRYER INLET/DISCHARGE
PORT
132-156 IN-LBS
7/8-14 PLUMBING
CONNECTIONS
COMPRESSOR SUCTION PORT
252-324 IN-LBS
¾-16 PLUMBING
CONNECTIONS
COMPRESSOR DISCHARGE PORT
180-240 IN LBS
7/16-20 PLUMBING
CONNECTIONS
EXPANSION VALVE INLET PORT
100-140 IN LBS
¾-16 PLUMBING
CONNECTIONS
EXPANSION VALVE OUTLET PORT
270-350 IN LBS
Table 1 Standard Torque Values
SUBTASK 21-00-23-99F-004
1.4 Documents required:
• Illustrated Parts Listings (IPL) (included with this manual)
• Pilatus PC12 Aircraft Maintenance Manual
SUBTASK 21-00-23-99F-005
1.5 Consumable Products:
ENVIRO PART
NUMBER
DESCRIPTION
REMARKS/ALTERNATE
PILATUS PART
NUMBER
11602
SEALANT RTV
BLACK RTV 103
P08-045
7471
THREAD SEALANT PRIMER
LOCTITE 7471
569
THREAD SEALANT
LOCTITE 569
RL-100H
POE REFRIGERANT OIL
R-134A
P10-021
Table 2 Consumable Products
