Enviro PILATUS PC12 - Figure 10001 Compressor Condenser Module Assembly (1134400-53) Details

Component Maintenance Manual
12037 N Highway 99
Seminole, OK 74868
Phone (405) 382-0731
Fax (405) 382-0737
http://www.enviro-ok.com
Copyright © 2017
ATA 21-00-23
Page | 70
Revision 10
June 1, 2017
FIG. ITEM PART NUMBER NOMENCLATURE UNITS ASSY.
10001-10C
1134104-1
DC MOTOR (-13 CONFIG ONLY)
1
See note below*
DC MOTOR ASSEMBLY (-56 CONFIG ONLY)
NP
1134104-6
DC MOTOR ASSEMBLY (-53 CONFIG)
1
11A
5/16-24X3/4H
UPPER/LOWER BOLT
2
12A
MS35333-41
FLAT WASHER
2
13A
5/16-24X3/4H
UPPER/LOWER BOLT
2
14A
NAS1149F0563P
FLAT WASHER (AN960-516) 2
15A
5/16-24X3/4H
UPPER BOLT
1
16A
MS35333-41
UPPER FLAT WASHER
1
17A
5/16-24X3/4H
LOWER DRIVE MOTOR BOLT
1
18A
MS35333-41
LOWER DRIVE MOTOR FLAT WASHER
1
19A
5/16-24X3/4H
UPPER/LOWER BOLT
2
20A
MS35333-41
FLAT WASHER
2
-21 1251171
MOTOR BRUSH (SET CONTAINS 4 BRUSH
PAIRS)
1
10B
1250128
POWER RELAY
1
-11B
¼-28X1/2H
BOLT
1
-12B
¼-28X1H
BOLT
1
-13B
21FK-428
NUT
2
-14B
MS35333-40
FLAT WASHER
1
-15B
AN345-416
NUT
1
-16B
NAS1149F0463P
FLAT WASHER (AN960-416)
4
-17B
MS25171-3
LARGE BOOT
3
-18B
MS25171-1
SMALL BOOT
2
21C
1250146-5
DRIVE PULLEY
1
-30
1134170-5
FAN BLADE (-53 CONFIG)
1
1134170
FAN BLADE (-13 CONFIG ONLY)
1
-31
¼-28X5/16B
SET SCREW
1
-32
NAS1149F0663P
FLAT WASHER (AN960-616)
3
-33
21FK-624
NUT
1
40A
1134160
COMPRESSOR ASSEMBLY
1
-41
M10-1.2525MM
BOLT
3
Figure 10001 Compressor Condenser Module Assembly (1134400-53) Details
Supersedes 1134400-13 and 1134400-56 – All configurations shown here
- ITEMS NOT ILLUSTRATED
N/P ITEMS NOT PROCURABLE
* For units that are the 1134400-56 configuration- when a motor requires service, the entire compressor
condenser module must be removed and returned to get upgraded to 1134400-53 or 1134400-59.
