Enviro PILATUS PC12 User Manual

Component Maintenance Manual
12037 N Highway 99
Seminole, OK 74868
Phone (405) 382-0731
Fax (405) 382-0737
http://www.enviro-ok.com
Copyright © 2017
ATA 21-00-23
Page | 71
Revision 10
June 1, 2017
FIG. ITEM PART NUMBER NOMENCLATURE
UNITS
ASSY.
-42A
10MM
SPLIT WASHER
3
-43
1134125-3
MANIFOLD ASSEMBLY
1
-44
AS568-013-HNBR-70
O-RING
1
-44
1134125-4
MANIFOLD ASSEMBLY
1
-45
901V212-10
O-RING TO FLARE ADAPTER
1
-46
AS568-015-HNBR-70
O-RING
1
50C
1134192-1
RECEIVER DRYER (Superseded by 1134192-15)
1
1134192-15
RECEIVER DYRER (Supersedes 1134192-1)
w/pressure switch
1
60A
1250232-4
BINARY PRESSURE SWITCH
1
70C
QS100M36H
CLAMP
2
80C
1134199
BELT COVER
1
-81
6-32X1/2IHS
SCREW
4
90C
240L100
DRIVE BELT
1
100A
1134510
OUTLET SHROUD
1
-101
10-32X3/8IHW
BOLT
4
-102
NAS1149F0332P
FLAT WASHER (AN960-10L)
4`
-103
409-1032Z
LOCK NUT
4
110A
1134509
FAN SHROUD
1
-111
10-32X1/2H
BOLT (RECEIVER DRYER BRACKET SIDE)
3
-112
NAS1149F0332P
FLAT WASHER (AN960-10L)
3
-113
409-1032-Z
LOCK NUT
3
-114
10-32X3/8IHW
BOLT
3
-115
NAS1149F0332P
FLAT WASHER (AN960-10L)
3
-116
409-1032Z
LOCK NUT
3
120A
CONDENSER COIL ASSEMBLY
N/P
130A
1134502-1
CONDENSER BRACKET
1
-131
MS35265-28
SCREW
4
-132
NAS1149FN632P
FLAT WASHER (AN960-6)
4
-133
MS35265-43
SCREW
3
-134
NAS1149FN832P
FLAT WASHER (AN960-8)
3
140C
1250703-3
HOUR METER
1
-141
AN500-A8-6
SCREW
2
-142
NAS1149FN632P
FLAT WASHER (AN960-6)
2
-143
409-632Z
LOCK NUT
2
150A
RECEIVER DRYER BRACKET
N/P
Figure 10001 Compressor Condenser Module Assembly (1134400-53) Details
Supersedes 1134400-13 and 1134400-56 – All Configurations shown here
- ITEMS NOT ILLUSTRATED
N/P ITEMS NOT PROCURABLE
