Component Maintenance Manual
12037 N Highway 99
Seminole, OK 74868
Phone (405) 382-0731
Fax (405) 382-0737
http://www.enviro-ok.com
9.1.5 Tools, fixtures, equipment, or consumable items required
• Small hand tools and socket set
• Gates Sonic Tension Meter 508C or equivalent
• Shop air, 40 PSIG max
• Scribe or wire hook
• Inspection mirror
• Thermometer, 0-150°F
• Flash light or service lamp
• Leak check fluid (soapy), (MS-SNOOP-GAL)
• Thread sealant primer
• Thread sealant
• Dry nitrogen, regulated (0-300 PSIG)
SUBTASK 21-00-23-40-001
9.2 Compressor Condenser Module Assembly Procedures
(refer to Figure 10001):
9.2.1 Assembly of Drive Motor Brushes (refer to IPL for details)
CAUTION: IT IS EXTREMELY IMPORTANT THAT THE BRUSH SHUNT WIRES DO NOT CONTACT THE
MOTOR HOUSING OR BRUSH COVER. THE MOTOR BRUSH SHUNT WIRES CARRY ALL OF THE
REQUIRED POSITIVE CURRENT FOR THE MOTOR TO OPERATE, THE MOTOR HOUSING IS/MAY BE
GROUNDED. ALLOWING THE SHUNT WIRES TO CONTACT THESE SURFACES WILL CAUSE A DIRECT
SHORT AND COULD CAUSE PREMATURE FAILURE OR OTHER DAMAGE.
CAUTION: ENSURE THAT MOTOR COMMUTATOR IS CLEAR OF ANY CONTAMINATION AND THAT
ALL CARBON DUST IS REMOVED.
CAUTION: DO NOT ALLOW BRUSH SPRING TO SNAP AGAINST THE BRUSH OR BRUSH DAMAGE
MAY RESULT.
