Component Maintenance Manual
12037 N Highway 99
Seminole, OK 74868
Phone (405) 382-0731
Fax (405) 382-0737
http://www.enviro-ok.com
Copyright © 2017
ATA 21-00-23
Page | 77
Revision 10
June 1, 2017
FIG. ITEM PART NUMBER NOMENCLATURE UNITS ASSY.
10003-10B
1133210-16
BRUSHLESS DC MOTOR (-60)
1
1133210-15
BRUSHLESS DC MOTOR (-61)
1
1133210-17
BRUSHLESS DC MOTOR (-63)
1
20B
1250219-1
BLOWER WHEEL (-60)
1
1250219-2
BLOWER WHEEL (-61/-63)
1
30C
BLOWER SCROLL
N/P
40A
SHROUD
N/P
50A
ESCUTCHEON
N/P
60A
1134218
EXPANSION VALVE (-60)
1
1134218-1
EXPANSION VALVE (-61/-63)
1
70D
1250540-11
AIR FILTER
1
-71
190940
VELCRO (HOOK) (2.6 FT.)
1
-72
190911
VELCRO (LOOP) (2.6 FT.)
1
80B
¼-28X25
SET SCREW
1
90B
4259
SPACER
2
100B
NAS1096-2-10
SCREW (8-32XX5/8)
2
110B
MS35333-38
LOCK WASHER
4
120B
NAS1096-2-20
SCREW (8-32X1-1/4)
2
130B
NAS1149FN832P
FLAT WASHER (AN960-8)
1
140B
CLN3/16
CLAMP
1
150A
1250823-5
DRIP TRAY (-60)
1
1250823-4
DRIP TRAY (-61/-63)
1
Figure 10003 Evaporator Module Assembly (1134200-60/-61/-63) Details
- ITEMS NOT ILLUSTRATED
N/P ITEMS NOT PROCURABLE
