ENVO D50 | ST50 EBIKE MANUAL | VERSION 1.0 24
4.5.3. LAMP AND FRONT FENDER MOUNTING
• Remove the Allen bolt Figure 4I
• Place the fender behind the fork bridge, and screw it into
place
• Align Fender stay mount to the fork, use an allen key to
fasten the screw Figure 4J
• Repeat steps for the other side
4.5.4. FRONT LIGHT
• The front light will come assembled on the handlebar,
use the allen key to fasten it to the handlbar as shown in
Figure 4K
Figure 4I
Figure 4J
Figure 4N
