4.5. ASSEMBLY & INSTALLATION
4.5.1. ENVO E50 ASSEMBLY
• Place the scooter on the ground by engaging the kickstand as shown in Figure 4A
• Connect the waterproof cable going from cockpit of the scooter into folding stem
• Insert the handlebar stem into the folding stem
• Lock the folding stem in place using the clamp, a “click” sound will let you know when the
clamp is engaged
• After the folding stem is secured, fasten the handlebar stem on to the folding stem using four
counter sink screws using 2.5mm allen key as shown in Figure 4B
Figure 4A Figure 4B
Improper assembly of the scooter may result in serious injury or even death. Make sure you
seek the help of a qualied mechanic in case of any doubt.
