ep WPL201 - Page 34

REV. 09/2020
B16
2.Steering
Rotate the operation hand shank leftward or rightward as required.
Rightward
Leftward
Example
Example
3.Braking
Mechanical operating brake
The truck is braked when the operating
handle is released.
The mechanical brake engages when the
tiller is positioned in Braking area.
Braking
area
Braking
area
Ifthecontrolhandlemovesslowlyinto
the brake position, identify the cause
andrectifythefault.Ifnecessary,
replace the gas spring!
CAUTION
