Epelsa ECO MULTIFUNCTION - Stop Bits Configuration

47
GBU-ECO-MF-V01
Possible
values
Default value
NO NO
EVEN
ODD
9.2.12 Number of bits (only if the connection type is different from ‘NO CONX’)
This selects the number of bits of the data transmitted and received.
Select the value by pressing the or keys and confirm with
the key. You will now go to the next parameter to be programmed.
Possible values Default value
7 8
8
9.2.13 Number of stop bits (only if the connection type is different from ‘NO CONX’)
This selects the communication’s number of stop bits.
8
NUMBER
BITS
Max 15 kg
Min 100 g
e= 5 g
I I I
kg
kg
Pcs
T
PT
