Epever MT50 - Page 22

18
1) Batt. Type
Supported battery types are shown as below:
1
Battery
Sealed(default)
Gel
Flooded
2
Lithium
battery
LiFePO4(4S/8S/15S/16S)
Li(NiCoMn)O2 (3S/6S/7S/13S/14S)
3
User 
 If the controller connected to the MT50 supports 48V system voltage, the
battery type will display LiFePO4 15S/16S and Li(NiCoMn)O2 13S/14S.
 When switching the battery type to "USE," the default voltage point is the
corresponding voltage before the battery type is modified.
2) Parameters of the Batt. AH, Temp Comp. Coeff and Rated Voltage
Parameters
Default
Range
Battery Ah
200Ah
1~9999Ah
Temperature compensation
coefficient
-3mv/℃/2V
0~-9mv/℃/2V
Rated voltage 
Auto
Auto/12V/24V/36V/48V
 When the battery type is selected as the lithium battery(LiFePO4 and
