Epever MT50 - Control parameter

17
test operation.
4.6 Control parameter
Browse, and modification operations are conducted over the control parameters
of the solar controller. See the scope of parameter modification in the control
parameters table and the page of control parameters in the diagram below:
Over Volt. Disc
16.0V
Charge Limit
15.0V
Batt. Type
Sealed
Batt. AH
200AH
Temp Comp.Coeff
-3mv/℃/2V
Rated Voltage
12V
Boost Rec.
13.2V
Low Volt. Rect.
12.6V
Ooer Volt. Rec.
15.0V
Eugal. Charge
14.6V
Boost Charge
14.4V
Float Charge
13.8V
Equalize Time
120min
Boost Time
120min
Under Volt. Rect
12.2V
Under Volt. Warn
12.0V
Low Volt. Disc
11.1V
Discharge Limit
10.6V
