24
 Please refer to the user guide or contact the sales for the details of setting
operations.
4.7 Load setting
The page of load setting could be used to set the four load working modes of the
connection solar controller (Manual, Light on/off, Light on + timer, Time control)
√Manual Control
◎Light On/off
◎Light On+Timer
◎Time Control
Manual Control
Default : ON
◎Manual Control
√Light On/off
◎Light On+Timer
◎Time Control
Light On/Off
On 05.0V DeT 10M
Off 06.0V DeT 10M
Light On+Timer
OnTime1 01H:00M
OnTime2 01H:00M
◎Manual Control
◎Light On/off
√Light On+Timer
◎Time Control
Light On+Timer
On 05.0V DeT 10M
Off 06.0V DeT 10M
NightTime10H:00M
Time Control
□Time2
OnTime 19:00:00
OffTime 19:00:00
◎Manual Control
◎Light On/off
◎Light On+Timer
√Time Control
Time Control
■Time1
OnTime 10:00:00
OffTime 19:00:00
