The load is on if the battery capacity is enough and no abnormal
conditions
happen.
The load is off all
the
time.
Light On
voltage(Night
threshold)
The load output is automatically turned
on when the bellows
occur at the same time:
1. The solar module's input voltage is lower
than the Light On
voltage.
2. The battery capacity is enough.
3. No abnormal conditions happen.
Light Off
voltage(Day
threshold)
When the solar module's input voltage is higher
than the Light Off
voltage, the load output is automatically turned
off.
It means the confirmation time for the light signal. During
this
period, if the light signal voltage continues matching the Light
On/Off voltage, the controller will perform corresponding actions
(the time adjustment range: 0~99mins).
