21
No.
Item
Number
1
Solar controller
1 pcs
2
Inverter
1 pcs
3
MT75
1 pcs
4
RS485-1M2S module
1 pcs
5
WIFI module, BT
module, or USB cable
1 pcs
6
Mobile phone or PC
1 pcs
7
RS485 cable(Included)
4 pcs
(2 pcs included, 2 pcs optional )
8
Dry contact connection
cable(Optional)
1 pcs
9
Power cable
1 pcs
10
PV, battery, AC load,
DC load
According to actual needs
3) Operations
1. Connect the main port of RS485-1M2S to controller and inverter.
2. Connect the slave port of RS485-1M2S to MT75 and
