3
3. Appearance
❶
Decorative shell
❽
Battery parameter button
❷
PV indicator
❾
PV parameter button
❸
Battery indicator
❿
Base (optional)
❹
Load indicator
⓫
Dry contact interface
①
❺
LCD
⓬
RS485 port 1(RJ45)
❻
Load ON/OFF button
⓭
RS485 port 2(RJ45)
❼
Load parameter
button
⓮
Dry contact
enable switch
①
