4
① Working Principle:
Dry
contact
Dry contact
enable switch
+5V
GND
Dry contact
Interface
Dry contact rated value: 5A/30VDC; Max. value: 0.5A/60VDC
Note: Turn the dry contact enable switch⓮ to ON only when the dry
contact is used, and turn it OFF when not used to save the dry contact's
loss.
