What to do if the Epever TRIRON3210N is not working even when the wire connection is correct?
If your Epever Controller isn't working despite correct wire connections, the battery voltage may be too low. Ensure the battery voltage is at least 9V to activate the controller.
Why is the charging LED indicator off on my Epever TRIRON3210N Controller during the day with proper sunshine on the PV modules?
The charging LED indicator might be off because of a PV array disconnection. Confirm that the PV and battery wire connections are correct and tight.
General| Model | TRIRON3210N |
|---|---|
| Type | Solar Charge Controller |
| System Voltage | 12V/24V Auto |
| Rated Charge Current | 30A |
| Rated Load Current | 20A |
| Max. PV Open Circuit Voltage | 100V |
| Max. PV Input Power | 390W (12V) / 780W (24V) |
| Efficiency | ≤98% |
| Self-consumption | ≤ 10mA |
| Charge Circuit Voltage Drop | ≤0.26V |
| Discharge Circuit Voltage Drop | ≤0.15V |
| Altitude | ≤3000m |
| Cooling | Natural Cooling |
| Weight | 1.2kg |
| Temperature Compensation | -3mV/°C/2V (Default) |
| Communication | RS485 |
| Protection | Overcharge / Over-discharge / Overload / Short-circuit |
| Operating Temperature | +55°C |
| Humidity | ≤95% (N.C.) |
| Battery Type | Sealed, Gel, Flooded, LiFePO4 |
Read all instructions and warnings before installation. Do not disassemble.
Introduction to TRIRON series modular MPPT solar charge controllers and their features.
Detailed description of the product's physical features and connection terminals.
Details on Power Modules and Display Modules for TRIRON controllers.
Explanation of the naming convention used for TRIRON series controllers.
Important precautions and guidelines to follow during the installation process.
Specifications and calculations for PV array configuration and module connections.
Guidelines for selecting appropriate wire sizes for PV and battery/load connections.
Instructions and recommendations for securely mounting the controller for optimal performance.
Detailed explanation of the DB1, DS1, and DS2 display modules and their indicators.
Description of USB, RS485, and Relay interface modules for connectivity.
Configuration of battery types, voltage, capacity, and temperature settings.
Explanation of different load control modes like Timers and Manual mode.
Overview of the controller's built-in protection functions against electrical faults.
Common faults, their possible reasons, and recommended troubleshooting steps.
Recommended periodic inspections and maintenance tasks for optimal performance.
