Safety and operating instructions
© Construction Tools GmbH | 3390 5203 01 | 2019-08-06
Original Instructions
49
7.11 Piston accumulator
The pressure in the piston accumulator is measured at
the filling valve(G). The piston accumulator is also filled
through this valve.
HB3100, HB3100DP
HB3600, HB3600DP
HB4700, HB4700DP
HB4100, HB4100DP
The following accessories can be supplied:
1 nitrogen filling device
1 test pressure gauge ¼", 0-25 bar, test category 1.6
1 nitrogen bottle
1 adapter, country-specific
To enable the following inspection and maintenance ac-
tivities to be carried out, the equipment referred to above
has to be directly available at the location of use at all
times.
