Nut
Bolt
5. Mounting bracket installation
Assemble the mounting bracket with
bolts and then install them to the
pre-installed flange plate on the ground
and lock tight with nuts.
Mounting bracket
Washer
305mm
Drain outlet
3. Cardboard installation
Align cardboard with the centerline of
drain outlet.
Draw contour line according to cardboard.
4. Hose
Connect the water inlet and angle valve
of the toilet with the matching hose and
tighten it.
Note:
Please use this supplied water supply hose,
to ensure optimal flushing performance.
Angle valve
connector
Inlet connector
Flexible hose
11
