battery
Note:
1. It is recommended to hire professional
personnel for this operation.
2. It is recommended to use 9V high-quality
dry battery, such as models 6LR61 or 6F22.
3. There is no battery installed in the battery
box in the configuration. It should be
purchased by the customer before installation.
4. It is recommended to replace the battery
every two years, otherwise there may be a
risk of leakage.
2. Installation of battery box
46.4mm
48.5mm
17.5mm
26.5mm
Female
buckle (-)
Male
buckle (+)
Toilet installation
Draw drain outlet centerline on the floor.
Install angle valve at proper position on
the wall according to the dimension of
toilet.
1. Installation of angle valve
Line
Drain outlet
Angle valve
Note:
1. Please use the supplied angle valve when
installing this toilet. Use of another angle
valve not including a filter may result in
blockages in the toilet and bidet waterways.
2. If replacing an existing angle valve, please
contact a professional for installation.
5/8′′
Installation Method 1:
Installation Method 2:
NPT 1/2
Before activating the power-off flushing
function, install a 9V alkaline battery (not
supplied) into the battery box in advance.
Take out the battery connection cable
from the rear side of seat cover. And
connect it to the female end of the
battery box, ensuring that it is plugged
in place.
Remove the sticker on the velcro at the
bottom of the battery box and place it in
the proper position of the ceramic back
for easy removal.
10
To Next Page
