09
6.Screw installation
Put the screw through the fixing sleeve and
then install it through the holes(on both sides
of the toilet ceramic) to the mounting bracket
on the ground, and lock tight with a tool;
Put the decorative cap on the fixing sleeve.
Fixing sleeve
Screw
Decorative cap
Nut
Bolt
4.Mounting bracket installation
Mounting bracket
Washer
Toilet drain outlet
Sealing flange
5.Ceramic toilet installation
Install sealing flange on drain outlet;
Install ceramic toilet on corresponding
position according to contour line.
Assemble the mounting bracket with bolts
and then secure them to the pre-installed
flange on the ground and tighten with nuts.
Tips:
1.The toilet is heavy, a it needs to open the
seat cover and carry by 2 adults.
2.Clean drain outlet before installation.
3.Make make sure ceramic toilet outlet sits
perfectly on drain outlet.
