U Page 44
Digital controller RK 4004
.7.0. reserved 70
Not assigned at present.
.7.1. reserved 71
Not assigned at present.
.7.2. running time meter
The operating hours of the control card are displayed here.
.7.3. supplyvoltage 24 DC
The current supply voltage of the controllercard is displayed.
.7.4. temperature case
The current temperature of the controller card case is displayed here.
.7.5. temp. case max.
The controller card stores the highest measured temperature of the
heat sink. This stored temperature is displayed.
.7.6. reserved 76
Not assigned at present.
.7.7. reserved 77
Not assigned at present.
.7.8. mainloops/sec.
For internal evaluations only.
.7.9. I/O confugiration
Parameter block for programming the digital inputs.
.8.0. digi input status
The current status of the digital controller card inputs is displayed
here.
.8.1. reserved 81
Not assigned at present.
