U Page 7
Digital controller RK 4004
Type RK 4004 AK 4002 LK 4203 RT 4019 DO 2000 AK 4014
DC 0310 X X
DC 0311 X X X
DC 0340 X
DC 0341 X X
DC 0360 X X
DC 0361 X X X
DC 1310 X X X
DC 1340 X X
DC 2340 X X
DC 2341 X X X
2. Type overview
The following table provides an overview of the most common digital
controllers. The individual digital controllers (DC) are listed in the ver-
tical column. The crosses mark the components belonging to them
(AK ...., LK ...., etc.).
3. Assembly
Controller card RK 40.. is usually mounted in a sheet steel housing or
E+L device.
If the controller card is supplied on its own it should be mounted in a
control cabinet away from heavy current-carrying modules.
The maximum distance to the DC actuator must not exceed
10 m.
