U Page 53
Digital controller RK 4004
➀ At this point the color line sensor loses its guiding criterion. The
web guider is blocked and the delay time set in parameter "1.0.1.
delaytime 1" started.
➁ On expiry of the set time switching to the emergency sensor takes
place and the web guider is enabled. Automatic mode is continued.
At the same time the controller card adopts the current actual web
position as the set position for the emergency sensor.
➂ The guiding criterion is available again and the delay time in para-
meter "1.0.2. delaytime 2" starts. Guiding is still performed by
emergency sensor.
➃ Once the set time has elapsed the system switches back to the
color line sensor.
1.0.3. subsystem 0 address
1.0.4. subsystem 1 address
1.0.5. subsystem 2 address
1.0.6. subsystem 3 address
Controller card RK 40.. features a serial bus connection. Up to 4 mo-
dules (e.g. a command station, several logic cards etc.) may be seri-
ally connected via this serial bus. The addresses of the serial devices
are entered automatically in ascending order beginning in parameter
1.0.3., (1st slot = address in parameter 1.0.3., 2nd slot = address in
parameter 1.0.4. etc). In the event of double addressing, the address
must be changed in the appropriate parameter. The place in front of
the dot specifies the group number and the place after the dot the de-
vice number.
Example:
Device number: A 9 F C
Group number: 0 0 3 7
Entry in parameter 0.A 0.9 3.F 7.C
1.0.7. calibration
Parameter block for calibrating the controller card.
1.0.8. calib. UDC
Scaling of operating voltage measuring and display. This parameter is
automatically set during the test run at E+L.
1.0.9. offset. I-act
Motor current offset measuring. This parameter is automatically set
during the test run at E+L.
1.1.0. calib. I-act
Scaling of motor current measuring and display. This parameter is au-
tomaticallly set during the test run at E+L.
