29
Installation
Concentrator plus/Vacufuge® plus
English (EN)
4.3.2 Complete system: Connecting the emission condenser
1. Unpack the emission condenser.
2. Remove the red cap from the upper connection.
3. Screw the angle connection to the side of the emission condenser.
4. Attach the hose to the pump outlet and the connection on the side of the emission condenser.
5. Attach the emission condenser from the side or from the front below the front left foot of the device.
WARNING! Risk of injury from overpressure.
An overpressure in the exhaust gas lines (e.g. caused by closed taps or blocked pipes) can
lead to bursting.
Only use pipes with a sufficiently large cross section.
Keep the exhaust gas line open.
Do not place any objects on the exhaust gas lines.
Do not flex the exhaust gas lines.
Do not fit any hose clamps or valves to the exhaust gas lines.
Note the maximum pressures and differential pressures permitted (see p. 56).
Check whether using the emission condenser is sufficient for the intended application. For the
concentration of chemically aggressive or biologically hazardous substances one of the
following measures must be taken:
•Replace the emission condenser with a suitable cold trap or chemical trap.
•In addition, place the emission condenser in an ice bath.
•Attach a hose to the upper connection of the emission condenser and connect it to an
extraction system.
•Set up a series connection of cold trap or chemical trap and emission condenser.
The pump of the device is fully solvent resistant. Therefore the emission condenser can be
placed behind the pump.
The emission condenser inlet needs to be lower than the pump outlet to prevent liquid from
collecting in the hose.
