Installation
Concentrator plus/Vacufuge® plus
English (EN)
34
1. Disconnect the basic device 1 and the vacuum pump 7 from the power supply.
2. Connect barb P of the solenoid valve 4 to a connecting hose 3 and attach the other end of the
connecting hose to the pump connection 2 on the rear of the basic device.
3. Connect barb A of the solenoid valve 4 to a connecting hose 5 and attach the other end of the
connecting hose to the vacuum pump inlet 6.
4. Connect the plug of the solenoid valve 9 to the provided connector on the rear of the basic device 10
(connected mains/power supply voltage!).
5. Connect the basic device to the power supply 11.
6. Connect the vacuum pump to the power supply 8.
The vacuum pump is isolated from the device automatically before concentration is complete
by closing the solenoid valve which is piloted by the concentrator. You can also isolate the
vacuum pump from the device without a solenoid valve by manually closing an in-line valve
(e.g., stop valve with ground-in stopper).
