epro MMS 6950 W - Digital Signal Terminal Block Connections

Operating Kit MMS 6950 W Page 35
Hardware Installation DOPS and DAPS
Fig. 6 Backplane MMS 6351/00 2v3 Operations of Alarms and Channel Clear
Backplane MMS 6351/00 2v3 Verknüpfungen Alarme und Channel Clear
+24V
U2
OUTxa A / CCa A
OUTxb B / CCb B
OUTxa B / CCa B
OUTxb C / CCb C
OUTxa C / CCa C
OUTxb A / CCb A
(Modul A_1)
(Modul B_1)
(Modul C_1)
(Modul C_2)
(Modul B_2)
(Modul A_2)
