8. Insert the ribbon cartridge into the printer at an angle as shown below, then press firmly on both
sides of the cartridge to fit the plastic hooks into the slots on the printer.
Note:
Do not touch the white cable inside the printer.
9. Slide the ribbon guide into the print head until it clicks in place.
!
Caution:
When inserting the ribbon guide, press firmly until it clicks.
FX-890II/FX-890IIN/FX-2190II/FX-2190IIN User’s Guide
Options and Consumables 122
