Quality
Plain paper, recycled paper, and carbonless multipart forms with point gluing or paper
stapling on both sides
* When the front or bottom pull tractor is installed and under normal conditions, up to 7 copies (1 original + 6 copies) can be
used.
Note:
❏ Do not load thick paper, such as multipart forms with six or seven parts, in the rear slot.
❏ The ratio of the cut/uncut length at the perforation should be between 3:1 and 5:1.
❏ The thickness of the perforation part when extended should be 1mm or less.
❏ The perforation between pages should not extend all the way to the edges of the paper. Uncut length
on the edges should be 1mm or more.
❏ The horizontal and vertical perforation cuts should not cross.
❏ Print quality may deteriorate when printing on paper that uses paper stapling (single/double
stapling).
Continuous labels (front and bottom entry only):
Note:
Use only labels mounted on continuous backing sheets.
Minimum Maximum
FX-890II
FX-890IIN
FX-2190II
FX-2190IIN
Label size
See the figure below.
Width, backing sheet
101.6 mm (4.0 inch) 254.0 mm (10.0 inch) 406.4 mm (16.0 inch)
Length, backing sheet
101.6 mm (4.0 inch) 558.8 mm (22.0 inch)
Thickness, backing
sheet
0.07 mm (0.0028 inch) 0.09 mm (0.0035 inch)
Total thickness
0.16 mm (0.0063 inch) 0.19 mm (0.0075 inch)
Label weight
64 g/m (17 lb)
FX-890II/FX-890IIN/FX-2190II/FX-2190IIN User’s Guide
Product Information 149
