Epson DS-520 User Manual

You see this window:
3. Click the Scan icon.
4. Select any displayed scan settings you want to use.
Note: See the Help information in Document Capture Pro for details.
5. Click Scan.
You see a preview of your scan in the Document Capture Pro window.
6. Open the File menu and select Batch Save.
7. Click File Name Settings.
8. Select Apply job separation and click Separation Settings.
9. Select the method you used to separate the originals, select a folder name specification and click
OK.
10. Select any additional settings from the File Name Settings dialog and click OK.
11. Select any additional settings from the Batch Save dialog and click OK.
45

Epson DS-520 Specifications

General

Duplex Scanning	Yes
Optical Resolution	600 dpi
Maximum Resolution	1200 dpi
ADF Capacity	50 sheets
Interface	USB 2.0
Maximum Document Size	8.5" x 72"
Daily Duty Cycle	3000 pages
Power Consumption	3.5 W (Ready)
Supported Operating Systems	Windows, macOS
