Epson DS-520 User Manual

10. Press down on the separation roller cover latch inside the scanner cover and pull down the cover to
open it.
Caution: Be careful not to apply too much force when opening the cover.
11. Press in on the separation roller to release it, then slide the roller to the side and remove it.
12. Pull the release tab on the separation roller and remove it from the spindle.
56

Epson DS-520 Specifications

General

Duplex Scanning	Yes
Optical Resolution	600 dpi
Maximum Resolution	1200 dpi
ADF Capacity	50 sheets
Interface	USB 2.0
Maximum Document Size	8.5" x 72"
Daily Duty Cycle	3000 pages
Power Consumption	3.5 W (Ready)
Supported Operating Systems	Windows, macOS
