Submenu Function
Video Signal
You can select the input signal from the S-Video port or the
Video port. If this is set to Auto, video signals are recognized
automatically. If interference appears in the image or a problem
occurs such as no image is being projected when set to Auto,
select the appropriate signal depending on the connected
equipment.
Aspect
You can set the
aspect ratio
g
for projected images.
s "Changing the Aspect Ratio of the Projected Image " p.42
Overscan
(This setting can only be adjusted when a component video or
RGB video signal is being input.)
Changes the output image ratio (the range of the projected
image). You can set the cropping range to Off, 4%, or 8%. When
the source is HDMI, Auto is available (EB-1880/EB-1870/
EB-1850W only). When Auto is selected, it automatically
changes to Off or 8% according to the input signal.
Reset
You can reset all adjustment values on the Signal menu to their
default settings, except for Input Signal.
See the following to return all menu items to their default
settings.
s "Reset Menu" p.89
Settings Menu
Submenu Function
Keystone
You can correct keystone distortion.
• When H/V-Keystone is selected:
Adjust V-Keystone and H-Keystone to correct horizontal
and vertical keystone distortion.
You can also set H-Keystone Adjuster (EB-1880/EB-1870/
EB-1850W only) and Auto V-Keystone to On or Off.
s "Correcting Keystone Distortion" p.35
• When Quick Corner is selected:
Select and correct the four corners of the projected image.
s "Quick Corner" p.37
Control Panel
Lock
You can use this to restrict operation of the projector's control
panel.
s "Restricting Operation (Control Panel Lock)" p.61
List of Functions
79
