EB-E01 series Disassembly and Assembly INTERNAL USE ONLY
SEIKO EPSON 141 Revision A
3.5 Individual Function Check After Repair
After performing repair work such as parts replacement of this projector, or disassembling/reassembling the projector, carry out the safety check and the basic
operation check of thefunctions of the projector following the instructions in this section.
REPAIRING PART - OPERATION AND SAFETY CHECK AFTER REPAIR TABLE
When repairing the part indicated as "Repairing part" in the left column on the table, operate the work marked with "o".
The work indicated on the table is the basic items. Put necessary work into effect additionally according to the situation of the repaired product.
Repairing part
Operation and Safety Check
Safety Check
Initialization
Check
Operation Check for
Control Panel
Operation Check
for Remote
Controller
Operation Check for
Video Input/Output
Operation Check
for Audio Input/
Output
Communication
Check
Power Button o o
Remote Controller o o
Video Input/Output o o
Audio Input/Output o o
Safety Device oooooo
MA Board o
Optical engine o o
Communication o
Reference P.142 P.145 P.145 P.145 P.146 P.146 P.147
