Epson EB-E01 Service Manual

EB-E01 series Disassembly and Assembly INTERNAL USE ONLY
SEIKO EPSON 150 Revision A
3.5.10 Service tool list
The following table describes the link of the basic operation manuals and the function about the service tools at 3.5.9 The service tools and the adjustment tasks list
which required before and after parts replacement (p148).
Optical engine --- ---
Take the DR data from the "Intramart" data base. (Intramart)
" 3.5.10 Service tool list (p150)"
Write the DR data of Optical Engine to the MA Board. (CAT)
" 3.6 Writing the DR Data (p152)"
*2: Calibrate on for (Screen Fit/Frame Fit/Easy setup).** Non-applied for this model.
Perform the Panel Alignment. **
" 3.8 LCD Alignment (p162)"
Lamp --- --- Initialize the Lamp information. (AS menu)
" 4.1.3 Initializing (Resetting) (p190)"
Replaced part name
Power on
was possible/
impossible
Before/after
replacement
Required adjustment tasks (service tools name) Reference for the tasks
Tool Name
Necessary to
update
Function
Basic operation manuals
TI-No Reference File name
IPS Tool
Referring to the projector
information.
Obtaining the AS menu information.
AP14-0916-01
Tech Exchange TI
(Utilty/Tool)
IPS-Tool_Manual(E).xlsx
Writing the projector IPS-
Tool_Manual
(E).xlsxinformation.
Reading out the lamp operation time from the MA
Board.
Writing the lamp operation time to the MA Board.
Updating firmware. Writing the firmware to the LCP.
CAT o
Reading the DR data from the old MA Board ofa failed
LCP and save them as file on PC.
Writing the DR-data from PC to the new MA Board
ofthe LCP.
AP08-0912E
Tech Exchange TI
(Utilty/Tool)
SERVICE_TOOL_MANUAL_E_*.
pdf
Intra-mart Delivery system for the DR data. AP08-0912E
Tech Exchange TI
(Utilty/Tool)
RESCUE o Set the destination. RE001
Tech Exchange TI
(Utilty/Tool)
USB firmware for updater Writing the firmware to the LCP by USB or USB cable.
Tech Exchange TI
(General)
Firmware Ver.**(bin file) release for
USB Updater
Easy MP Network firmware for updater
Firmware
Updating the firmware of the LCP by wire network.
Tech Exchange TI
(General)
Firmware Ver.**(bin file) release for
EasyMPNetwork Update

Epson EB-E01 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	0 - 1.76 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Supported aspect ratios	16:10, 16:9
Contrast ratio (typical)	15000:1
Screen size compatibility	- \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2200 ANSI lumens
RMS rated power	2 W
Focus	Manual
Throw ratio	1.44 - 1.95:1
Fixed focal length	16.7 mm
Lamp type	UHE
Lamp power	210 W
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Placement	Ceiling, Desktop
Product type	Short throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Built-in display	No
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Bundled software	Inhalt DIY-App, Epson Projektor Management, Epson Projektor Professional Tool
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
USB display function	2 in 1: Image / Mouse
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	126 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2400 g
Package depth	378 mm
Package width	329 mm
Package height	150 mm
Package weight	3500 g
