EB-E01 series Disassembly and Assembly INTERNAL USE ONLY
SEIKO EPSON 71 Revision A
Standard
operation time
(minutes)
-
1
4
8
9
10
11
13
14
18
20
A
Start
3.3.3 Front Foot (p75)
3.3.6 Upper Case
(Assy) (p80)
Housing/
consumables
Boards/
Optical parts
Cooling system
parts
Assembly
(not ASP)
Parts that should be removed
before removing target parts
[Items and colors]
3.3.2 Lamp (p74)
3.3.10 MA Board Assy
(p100)
Fastest way
Fastest way flowchart for 3.4 Shortest removal
procedures of identified failed parts (p137)
Typical Disassembly Flowchart
3.3.1 Air Filter (p73)
3.3.8 P3dash Module
(p96)
3.3.7 WFD Board
(p94)
3.3.5 Rear Case (p77)
3.3.10.1 Speaker 16W
(p105)
3.4.4 EX Fan (p140)
Fastest way
3.3.6.2 H Key Assy/
Upper Case (p86)
3.3.6.1 SW Board
(p84)
3.3.4 Rear Foot (p76)
3.3.6.4 Upper Case
(p89)
3.3.8 P3dash Module
(p96)
3.3.9 RTC Board
(p97)
3.3.6.3 Shutter (p87)
3.3.9 RTC Board
(p97)
B
3.4.1 Speaker (p137) 3.4.2 IR Board (p138) 3.4.3 LMP Thermistor
(p139)
3.3.15 P4combo
Module (p128)
(>> 72)
