Crestron Connected Support
121
h
When you finish selecting settings, click Exit to exit the program.
gg Related Links
"Crestron Connected Operation Window" p.121
"Crestron Connected Tools Window" p.122
Crestron Connected Operation Window
Settings on the operation window let you control the projector and adjust the
projection image.
A
Power Turns the projector on or off.
Vol-/Vol+ Adjusts the volume.
A/V Mute Turns the video and audio on or off.
B
Switches to the image from the selected input source. To display input sources
that are not shown in Sources List, click (a) or (b) to scroll up or down. The
current video signal input source is displayed in blue.
You can change the source name if necessary.
C
Freeze Images are paused or released.
Contrast Adjusts the difference between light and shade in the
images.
Brightness Adjusts the image brightness.
Color Adjusts the color saturation for the images.
Sharpness Adjusts the image sharpness.
Zoom Enlarges or reduces the image without changing the
projection size. Click the arrow buttons to change the
position of an enlarged image.
D
Arrow buttons Performs the same operations as the arrow buttons on
the remote control.
OK Performs the same operation as [Enter] on the remote
control.
Menu Displays and closes the projector's menu.
Auto Optimizes Tracking, Sync., and Position in the
projector's Signal menu while projecting an analog
RGB signal from Computer1 or Computer2 port.
Search Changes to the next input source that is sending an
image.
Esc Performs the same operation as the [Esc] button on the
remote control.
E
Tools Changes settings in the projector that is currently
connected.
Info Displays information on the projector that is currently
connected.
Help Displays the Help Desk window. Used to send
messages to, and receive messages from, the
administrator using Crestron RoomView Express.
