Projector Connections
32
b
Connect the USB cable or USB flash drive to the projector's USB-A port
as shown.
Attention
Use the USB cable supplied with or specified for use with the device.
Do not connect a USB hub or a USB cable longer than 3 meters, or the
device may not operate correctly.
c
Connect the other end to your device, if necessary.
gg Related Links
"List of Functions" p.10
Disconnecting a USB Device
When you have finished presenting with a connected USB device, disconnect
the device from the projector.
a
Turn off and unplug the device, if necessary.
b
Disconnect the USB device from the projector.
Connecting to a Document Camera
You can connect a document camera to your projector to project images
viewed by the camera.
The connection method varies depending on your Epson document camera
model. See the document camera manual for details.
gg Related Links
"List of Functions" p.10
Connecting to External Devices
Follow the instructions in these sections to connect external devices to the
projector.
gg Related Links
"Connecting to a VGA Monitor" p.32
"Connecting to External Speakers" p.33
"Connecting a Microphone" p.34
Connecting to a VGA Monitor
If you connected the projector to a computer using a Computer port, you can
also connect an external monitor to the projector. This lets you see your
presentation on the external monitor even when the projected image is not
visible.
a
If you want to output images to an external monitor when the
projector is turned off, select Always On as the A/V Output setting
in the projector's Extended menu.
s Extended > A/V Settings > A/V Output
Monitors that use a refresh rate of less than 60 Hz may not be able to
display images correctly.
a
Make sure your computer is connected to the projector's Computer
port.
