Epson EB-E01 User Manual

Contents
2
Notations Used in This Guide 7
Using the Manual to Search for Information .................................. 8
Searching by Keyword................................................................................................................... 8
Jumping Directly from Bookmarks............................................................................................ 8
Printing Only the Pages You Need............................................................................................ 8
Getting the Latest Version of the Documents................................. 9
List of Functions 10
Introduction to Your Projector 14
Projector Features............................................................................ 15
Quick and Easy Setup .................................................................................................................. 15
Easy Wireless Projection ............................................................................................................. 15
Projector Parts and Functions ........................................................ 17
Projector Parts - Front.................................................................................................................. 17
Projector Parts - Rear.................................................................................................................... 18
Projector Parts - Base ................................................................................................................... 19
Projector Parts - Control Panel................................................................................................. 20
Projector Parts - Remote Control ............................................................................................ 21
Setting Up the Projector 23
Projector Placement ........................................................................ 24
Projector Setup and Installation Options............................................................................. 25
Projection Distance....................................................................................................................... 25
Projector Connections ..................................................................... 27
Connecting to a Computer........................................................................................................ 27
Connecting to a Computer for VGA Video and Audio.............................................. 27
Connecting to a Computer for USB Video and Audio............................................... 28
Connecting to a Computer for HDMI Video and Audio ........................................... 29
Connecting to Video Sources ................................................................................................... 29
Connecting to an HDMI Video Source ............................................................................ 30
Connecting to a Composite Video Source..................................................................... 30
Connecting to External USB Devices ..................................................................................... 31
USB Device Projection ........................................................................................................... 31
Connecting to a USB Device ............................................................................................... 31
Disconnecting a USB Device ............................................................................................... 32
Connecting to a Document Camera ...................................................................................... 32
Connecting to External Devices............................................................................................... 32
Connecting to a VGA Monitor ............................................................................................ 32
Connecting to External Speakers ...................................................................................... 33
Connecting a Microphone ................................................................................................... 34
Installing Batteries in the Remote Control.................................... 35
Remote Control Operation.............................................................. 36
Opening the Lens Cover .................................................................. 37
Using Basic Projector Features 38
Turning On the Projector ................................................................ 39
Home Screen................................................................................................................................... 40
Turning Off the Projector ................................................................ 42
Setting the Date and Time .............................................................. 43
Selecting the Language for the Projector Menus ......................... 45
Projection Modes ............................................................................. 46
Changing the Projection Mode Using the Remote Control.......................................... 46
Changing the Projection Mode Using the Menus ............................................................ 46
Displaying a Test Pattern ................................................................ 48
Adjusting the Image Height............................................................ 49
Image Shape..................................................................................... 50
Auto V-Keystone ............................................................................................................................ 50
Correcting the Image Shape with the Horizontal Keystone Slider............................. 50

Epson EB-E01 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	0 - 1.76 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Supported aspect ratios	16:10, 16:9
Contrast ratio (typical)	15000:1
Screen size compatibility	- \
Projector native resolution	XGA (1024x768)
Keystone correction, horizontal	-30 - 30 °
Projector brightness (economic mode)	2200 ANSI lumens
RMS rated power	2 W
Focus	Manual
Throw ratio	1.44 - 1.95:1
Fixed focal length	16.7 mm
Lamp type	UHE
Lamp power	210 W
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Placement	Ceiling, Desktop
Product type	Short throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Built-in display	No
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Bundled software	Inhalt DIY-App, Epson Projektor Management, Epson Projektor Professional Tool
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
USB display function	2 in 1: Image / Mouse
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	126 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2400 g
Package depth	378 mm
Package width	329 mm
Package height	150 mm
Package weight	3500 g
