Wireless Network Projection
98
Using a USB Key to Connect a Windows Computer
You can set up your USB flash drive as a USB key to quickly connect the
projector to a wireless LAN supported Windows computer. After creating the
USB key, you can quickly project images from the network projector.
a
Set up the USB key using Epson iProjection (Windows/Mac) software.
a
See the Epson iProjection Operation Guide (Windows/Mac) for
instructions.
b
Make sure the wireless LAN module is installed or built into your
projector.
c
Turn on the projector.
d
Press the [LAN] button on the remote control.
The LAN standby screen is displayed. Verify that an SSID and IP
address are displayed.
e
Do one of the following to connect the USB key.
Connect the USB key to the projector's USB-A port. (Models with a
built-in wireless LAN module.)
Remove the wireless LAN module from the projector and insert the
USB key into the same port used for the wireless LAN module.
(Models with the optional wireless LAN module installed.)
You see a projected message that the network information update is
complete.
f
Remove the USB key.
If your projector needs the wireless LAN module, reinsert the wireless
LAN module into the projector. (Models with the optional wireless
LAN module installed.)
g
Connect the USB key to a USB port on your computer.
h
Follow the on-screen instructions to install the necessary application.
a
If the Windows Firewall message is displayed, click Yes to
disable the firewall.
You need administrator authority to install the software.
If it is not installed automatically, double-click
MPPLaunch.exe in the USB key.
After a few minutes, your computer image is displayed by the projector.
i
When you have finished projecting wirelessly, select the Safely Remove
Hardware option in the Windows taskbar, and then remove the USB
key from your computer.
a
You may need to restart your computer to reactivate your
wireless LAN connection.

Table of Contents

Other manuals for Epson EB-E01

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Epson EB-E01 and is the answer not in the manual?

Epson EB-E01 Specifications

General IconGeneral
Matrix size0.55 \
Number of colors1.07 billion colors
Native aspect ratio4:3
Projection distance0 - 1.76 m
Vertical scan range100 - 120 Hz
Projection technology3LCD
Supported aspect ratios16:10, 16:9
Contrast ratio (typical)15000:1
Screen size compatibility- \
Projector native resolutionXGA (1024x768)
Keystone correction, horizontal-30 - 30 °
Projector brightness (economic mode)2200 ANSI lumens
RMS rated power2 W
FocusManual
Throw ratio1.44 - 1.95:1
Fixed focal length16.7 mm
Lamp typeUHE
Lamp power210 W
Light source typeLamp
Service life of light source6000 h
Service life of light source (economic mode)12000 h
PlacementCeiling, Desktop
Product typeShort throw projector
Product colorWhite
Market positioningPortable
Cable lock slot typeKensington
Built-in displayNo
Power sourceAC
AC input voltage100-240 V
AC input frequency50 - 60 Hz
Power consumption (standby)0.3 W
Power consumption (typical)327 W
Power consumption (economy mode)225 W
Video processing10 bit
Video color modesBlackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system-
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Operating temperature (T-T)5 - 35 °C
Storage relative humidity (H-H)10 - 90 %
Operating relative humidity (H-H)20 - 80 %
Bundled softwareInhalt DIY-App, Epson Projektor Management, Epson Projektor Professional Tool
Noise level37 dB
Country of originPhilippines
Noise level (economic mode)28 dB
USB display function2 in 1: Image / Mouse
Pallet weight0 g
Quantity per pack1 pc(s)
Quantity per pallet84 pc(s)
Quantity per pallet (UK)126 pc(s)
Harmonized System (HS) code85286200
Weight and Dimensions IconWeight and Dimensions
Depth237 mm
Width302 mm
Height82 mm
Weight2400 g
Package depth378 mm
Package width329 mm
Package height150 mm
Package weight3500 g
