Projector Parts and Functions
22
Name Function
A
Power button [ ]
Turns the projector on or off.
B
[HDMI] button Switches the image source between the HDMI ports.
C
[Computer] button Switches the image source to the Computer ports.
D
Numeric buttons Enters numbers in the projector's menu while holding
down the [Num] button.
E
[Auto] button Optimizes Tracking, Sync., and Position in the
projector's Signal menu while projecting an analog
RGB signal from the Computer ports.
F
[Num] button Hold down this button to enter numbers using the
numeric buttons.
G
[Menu] button Displays and closes the projector's menu.
H
Arrow buttons Selects menu items while displaying the projector's
menu.
I
[Enter] button [ ] Enters the current selection and moves to the next level
while displaying the projector's menu.
J
[User] button Performs settings assigned in the User Button setting
in the projector's Settings menu.
K
[Color Mode] button Changes the color mode.
L
[Aspect] button Changes the aspect mode.
M
[E-Zoom] +/–
buttons
Resizes the projected image.
N
[A/V Mute] button Turns the video and audio on or off temporarily.
O
[Split] button Projects two images from different image sources
simultaneously by splitting the projected screen.
P
[Home] button Displays and closes the Home screen.
Q
[Freeze] button Pauses or resumes images.
R
[Volume] up/down
buttons
Adjusts the speaker volume.
S
[Default] button Returns the selected setting to its default value.
Name Function
T
[Esc] button Stops the current function.
Moves back to the previous menu level while
displaying the projector's menu.
U
[ID] button Hold down this button and press the numeric buttons
to select the ID for the projector you want to operate
using the remote control.
V
[LAN] button Switches the image source between the network
connected devices.
W
[USB] button Switches the image source between the USB Display
and USB-A port.
X
[Source Search]
button
Switches to the next input source.
Y
Remote control light
emitting area
Outputs remote control signals.
gg Related Links
• "Image Aspect Ratio" p.58
• "Adjusting Image Quality (Color Mode)" p.61
• "Input Signal Settings - Signal Menu" p.131
• "Projector Setup Settings - Extended Menu" p.134
• "Home Screen" p.40
• "Projecting Two Images Simultaneously" p.65
• "Connecting to a Computer for USB Video and Audio" p.28
• "Projecting a PC Free Presentation" p.68
• "Using the Projector on a Network" p.87
