Epson EB-U32 - Projector Parts - Rear

12
Projector Parts and Functions
EB-U32/EB-U04/EB-U130
Name Function
K
Security slot The security slot is compatible with the Microsaver
Security System manufactured by Kensington.
L
Control panel Operates the projector.
M
Zoom ring Adjusts the image size.
(EB-U32/EB-
W32/EB-W31/EB-
X36/EB-X31/EB-
U04/EB-W04/EB-
X04/EB-U130/EB-
W130/EB-X130/EB-
X350/EB-X300)
N
Focus ring Adjusts the image focus.
O
Lamp cover Open to access the projector's lamp.
Name Function
A
Power inlet Connects the power cord to the projector.
gg Related Links
B
Wireless LAN module Secures the wireless LAN module cover.
• "Projector Indicators Status" p.135
fixing screw
• "Resizing the Image with the Zoom Ring" p.46
(EB-W31/EB-
• "Focusing the Image Using the Focus Ring" p.48
X36/EB-X31/EB-
S31/EB-W04/EB-
X04/EB-S04/EB-
Projector Parts - Rear
W130/EB-X130/EB-
S130/EB-X350/EB-
EB-W32/EB-W31/EB-X36/EB-X31/EB-S31/EB-W04/EB-X04/EB-S04/EB-
X300/EB-S300)
W130/EB-X130/EB-S130/EB-X350/EB-X300/EB-S300
C
Audio ports Inputs audio from equipment connected to the
Computer, S-Video, or Video port.
D
Video port Inputs composite video signals from video sources.
E
Remote receiver Receives signals from the remote control.
F
Speaker Outputs audio.
