Projector Connections
d
Connect the other end to the projector's Audio ports.
Connecting to an S-Video Video Source
If your video source has an S-Video port, you can connect it to the projector
using a commercially available S-Video cable (EB-W32/EB-W31/EB-X36/EB-
X31/EB-S31/EB-W04/EB-X04/EB-S04/EB-W130/EB-X130/EB-S130/EB-
X350/EB-X300/EB-S300).
You can play sound through the projector's speaker system by connecting a
commercially available RCA audio cable.
Make sure the audio cable is labeled "No resistance".
a
Connecting to a Composite Video Source
a
Connect the S-Video cable to your video source's S-Video output port.
If your video source has a composite video port, you can connect it to the
b
Connect the other end to the projector's S-Video port.
projector using a commercially available RCA-style video or A/V cable.
You can play sound through the projector's speaker system by connecting a
commercially available RCA audio cable.
Make sure the audio cable is labeled "No resistance".
a
a
Connect the cable with the yellow connector to your video source's
yellow video output port.
b
Connect the other end to the projector's Video port.
c
Connect the audio cable to your video source's audio-out ports.
