Epson EB-X06 Service Manual

EB-E01 series Disassembly and Assembly INTERNAL USE ONLY
SEIKO EPSON 148 Revision A
3.5.9 The service tools and the adjustment tasks list which required before and after parts replacement
The following table describes the service tools and adjustment tasks which required before and after parts replacement. Please refer to "The service tool list" about
their basic operation manuals.
**: Require for applied model only.
*1: Instruction: Write the current firmware immediately after MA Board is replaced.
*2: Instruction: Write the DR data to MA Board before calibration.
Gray out: Non-applied for this model.
Replaced part name
Power on
was possible/
impossible
Before/after
replacement
Required adjustment tasks (service tools name) Reference for the tasks
Optical Engine and MA
Board set
Possible
Before Read out the lamp operation time from the old MA Board. (IPS Tool)
" 3.5.10 Service tool list (p150)"
After
*1 Write the current firmware
by "USB for Updater" or "EasyMP Network for Updater" or (IPS Tool/IDOL).
" 3.5.10 Service tool list (p150)"
Set the destination. (RESCUE)
" 3.5.10 Service tool list (p150)"
Calibrate G-sensor.**
" 3.7 G Sensor Calibration (p161)"
Calibrate on for (Screen Fit/Frame Fit/Easy setup)** Non-applied for this model.
Set the commander and receiver for stack 3D display.** Non-applied for this model.
Set the "local time".**
" 3.3.9 RTC Board (p97)"
Write the lamp operation time to the new MA Board. (IPS Tool)
" 3.5.10 Service tool list (p150)"
Optical Engine and MA
Board set
Impossible After
*1 Write the current firmware
by "USB for Updater" or "EasyMP Network for Updater" or (IPS Tool/IDOL).
" 3.5.10 Service tool list (p150)"
Set the destination. (RESCUE)
" 3.5.10 Service tool list (p150)"
Calibrate G-sensor.**
" 3.7 G Sensor Calibration (p161)"
Calibrate on for (Screen Fit/Frame Fit/Easy setup)** Non-applied for this model.
Set the commander and receiver for stack 3D display.** Non-applied for this model.
Set the "local time".**
" 3.3.9 RTC Board (p97)"

Epson EB-X06 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	1.8 - 2.17 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-30 - 30 °
Projector brightness (economic mode)	2400 ANSI lumens
Lamp type	UHE
Lamp power	210 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Focus	Manual
Throw ratio	1.48 - 1.77:1
Zoom capability	Yes
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.49 - 1.72
3D	No
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
USB 2.0 ports quantity	2
Wi-Fi standards	802.11ad, 802.11b, Wi-Fi 4 (802.11n)
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
RMS rated power	2 W
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Recommended gender	Any gender
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, VGA
Bundled software	Inhalt DIY-App, EasyMP Multi PC Projection, Epson Projektor Management, Epson Projektor Professional Tool
USB display function	2 in 1: Image / Mouse
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	126 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2500 g
Package depth	380 mm
Package width	335 mm
Package height	150 mm
Package weight	3770 g
