Epson EB-X06 Service Manual

EB-E01 series Troubleshooting INTERNAL USE ONLY
SEIKO EPSON 55 Revision A
Connector
No.
Destination
Error Information
Phenomenon Reference
Error Name/
Device Name
Name
CN8700 Optical Engine (R L/V) --- ---
When pressing the power button, projection starts normally. But the black part of the
projected image is reddish.
P.60
CN8800 Optical Engine (G L/V) --- ---
When pressing the power button, projection starts normally. But the black part of the
projected image is greenish.
CN8900 Optical Engine (B L/V) --- ---
When pressing the power button, projection starts normally, then the projection starts.
But the black part of the projected image is bluish. (This phenomenon is not easily
recognized on Logo screen or No Signal screen; therefore try displaying the menu or
the like to check for it.)
CN3000 PS Unit (P/S) --- ---
When connecting the AC cable, the power LED does not light blue. The power button
does not work or power cannot turn on.
P.61
CN1600 AIR-TH Thermistor AIR
Sensor Error
The power can turn on and after the status LED blinks in blue, temperature LED blinks
in orange. When pressing the power button, initialization starts normally but sensor
error occurs while initializing. Then LEDs indicate the error, and then the projector
turns into the abnormal stand-by status
P.37
CN1601 LMP-TH Thermistor LMP
CN1602 LV-FAN Fan LV1
Fan Error
The power can turn on and after the status LED blinks in blue, temperature LED blinks
in orange. When pressing the power button, initialization starts normally but sensor
error occurs while initializing. Then LEDs indicate the error, and then the projector
turns into the abnormal stand-by status
P.37
CN1603 EX-FAN Fan EX
CN1604 LMP-FAN Fan LMP
CN500*
1
WFD Module WFD WFD error
The power can turn on and Power LED lights blue. Projection starts normally when the
power button is pressed, but the WFD does not function.
P.62
CN501*
1
CN1400 SW Board Cover Open Lamp cover open error
The power cannot be turned on with the operation panel. However, the power can be
turned on with the remote controller. When the power is turned on, the fan rotates at
high speed and turns off after a short while. Then the machine goes into abnormal
stand-by mode after displaying Lamp Cover Open Error.
P.62
CN1403 IR Board --- ---
Operates normally after the power turns on. However, IR receiver at the front stops
working.
P.62
CN1405*
1
RTC Board I2C Internal error
The power can turn on and Power LED lights blue. When pressing the power button,
initialization starts but instantly the projector changes to the Internal error mode. After
a certain period of cooling, the projector turns into the abnormal stand-by status. The
LED Indicator’s warning display continues until unplugging the AC cable.
P.62
CN1800*
2
P4Combo --- ---
The power can turn on and Power LED lights blue. Projection starts normally when the
power button is pressed, but the W-LAN does not function.
P.62

Epson EB-X06 Specifications

General

Matrix size	0.55 \
Number of colors	1.07 billion colors
Native aspect ratio	4:3
Projection distance	1.8 - 2.17 m
Vertical scan range	100 - 120 Hz
Projection technology	3LCD
Contrast ratio (typical)	16000:1
Screen size compatibility	30 - 300 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	-30 - 30 °
Projector brightness (economic mode)	2400 ANSI lumens
Lamp type	UHE
Lamp power	210 W
Lamps quantity	1 lamp(s)
Light source type	Lamp
Service life of light source	6000 h
Service life of light source (economic mode)	12000 h
Focus	Manual
Throw ratio	1.48 - 1.77:1
Zoom capability	Yes
Focal length range	16.9 - 20.28 mm
Aperture range (F-F)	1.49 - 1.72
3D	No
Video processing	10 bit
Video color modes	Blackboard, Cinema, Dynamic, Presentation, sRGB
Analog signal format system	-
USB 2.0 ports quantity	2
Wi-Fi standards	802.11ad, 802.11b, Wi-Fi 4 (802.11n)
Noise level	37 dB
Country of origin	Philippines
Noise level (economic mode)	28 dB
RMS rated power	2 W
Placement	Ceiling, Desktop
Product type	Standard throw projector
Product color	White
Market positioning	Portable
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Power consumption (typical)	327 W
Power consumption (economy mode)	225 W
Recommended gender	Any gender
Storage temperature (T-T)	-10 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	20 - 80 %
Cables included	AC, VGA
Bundled software	Inhalt DIY-App, EasyMP Multi PC Projection, Epson Projektor Management, Epson Projektor Professional Tool
USB display function	2 in 1: Image / Mouse
Pallet weight	0 g
Quantity per pack	1 pc(s)
Quantity per pallet	84 pc(s)
Quantity per pallet (UK)	126 pc(s)
Harmonized System (HS) code	85286200

Weight and Dimensions

Depth	237 mm
Width	302 mm
Height	82 mm
Weight	2500 g
Package depth	380 mm
Package width	335 mm
Package height	150 mm
Package weight	3770 g
