EB-S01/W01/X14G/S11/X11/S02/S02H/X02/W02/S12/S12H/X12/W12/X14 EH-TW480 Troubleshooting CONFIDENTIAL
SEIKO EPSON 27 Revision C
SENSORS/SPEAKER
Figure 2-5.
Speaker (p81)
TH Board (2) (p.88)
Shutter Switch (p70)
HK Assy (EB-X11/S12/S12H/X12/
W12/X14 EH-TW480 only) (p69)
IR Board (p.97)
TH Board (1) (p.97)
